CATHY Plus I.V Cannula

Single-use, sterile, non-pyrogenic, and non-toxic Cathy I.V Cannulas comes with & without Injection port and safety features also. With the new VOLEX proprietary polymer, Cathy I.V. Cannulas make a technological leap into the future of medical care. Equipped with a short bevel ‘back’ cut point, the stainless steel needles offer seamless catheterization. It ensures smooth blood withdrawals and transfusions while cause minimal pain even in the most delicate of I.V. cannulation sites.

The Cathy + I.V. cannula incorporates an activated safety feature using the SIP CLIP protection device, which covers the needle tip during the extraction of the introducer needle. This safeguards healthcare workers from needlestick injuries during cannulation and disposal, offering an effective blood collection and infusion.

Features

  • The Volex based PUR catheter, Cathy, and Cathy+ I.V. cannula, provides more durability, better sharpness, and high precision with Volex-made catheter.
  • Auto Protection in the safety version of Cathy + I.V. Cannula involves an activated safety feature utilizing the SIP CLIP protection device.
  • It covers the needle tip during introducer needle extraction, safeguarding healthcare workers from Needle Stick Injuries during cannulation and disposal.
  • Automatic Vision Inspections ensure tip quality, straightness, and length.
  • Angled and grooved wings help in easy fixation of the cannula in the patient’s body.
  • Provided with an easy-to-open injection port cap.
  • The three-facet cut needle point allows gentle insertion.
  • Equipped with a flash-back chamber in the hub, the component acts as a green signal for the user demonstrating successful cannulization of the device inside the patient.
  • Description
  • components
  • IFU
  • Infographic
  • Video
  • Luer-Lock tip
    Luer-Lock tip
    Our Luer-Lock tip is generally used for injections requiring a secure connection of the syringe to another device.
  • Luer slip tip
    Luer slip tip
    Our luer slip tip provides a friction-fit connection that requires you to push and twist the syringe tip into the needle hub.

Key Highlights

  • It’s a 2 way/1 way I.V. Cannula with wings.

  • It is provided with a low-pressure injection valve to facilitate extra medication and to prevent its backflow.

  • Medicine can be injected by a syringe without a needle thereby reducing the chances of infection and preventing needlestick injuries. The cost of the needle is also saved.

  • The valve is protected with easy to open Injection Port Cap.

  • Coloured Injection Port Cap for size identification.

  • It offers a safe and convenient method of atraumatic administration of medicines.

  • Angled & grooved wings offer easy fixation and prevent shifting & rolling of the cannula in the patient’s body.

  • Single-use, sterile, non-pyrogenic, and nontoxic.

  • The Wings are made up of nontoxic, medical-grade polypropylene compatible with any medication. The injection port and the receiving end of the wing have a 6% luer taper as per ISO:80369.

  • The Needle is made from cold-rolled stainless steel strips. The tip of the needle has a short bevel ‘back’ cut point for easy catheterization and minimal pain and risk of perforation.

Product Range

Specifications

Yellow 24G 0.70 x 19 22
Violet (without Injection Port) 26G 0.60 x 19 15
Colour Code Gauge Catheter Ext

Length (mm)

Water Flow Rate

(ml/min)

Orange 14G 2.2 × 45 310
Grey 16G 1.7 × 45 200
White 17G 1.5 × 45 140
Green 18G 1.2 × 38

1.2 × 45

105

100

Pink 20G 1.0 × 32 64
Blue 22G 0.8 × 25 38
Yellow 24G 0.7 × 19 16/22
Violet 26G 0.6 × 19 12/15
